Efficient CNN Multiplier Architecture

High-Performance & Energy-Efficient AI Accelerator

An AI Accelerator that helps edge devices compute what it offloaded to different servers.

Back to Projects View Poster

Problem Statement

Convolutional Neural Networks (CNNs) excel in image processing but are computationally expensive. Over 90% of computation comes from Multiply-Accumulate (MAC) operations. Conventional multipliers consume excessive power, occupy large silicon area, and suffer from high critical path delays.
Edge devices typically offload this compute to a server and wait for the output. This not only increased the latency, but also damages the privacy of the individial. Why not keep everything in house and respect people's time, energy and privacy?

Our Solution

We designed an efficient hardware multiplier architecture for CNN-based image processors using:

  • Radix-4 Booth Encoding to reduce partial products by 50%
  • High-speed 4:2 Compressor Trees to shorten critical path delay
  • SRAM Memory Tiling for reduced memory bandwidth and faster computation

Hardware Processing Pipeline

  1. Input Image → Preprocessing (224x224 RGB, Int8)
  2. SRAM Tiling → Fetch initial 3x3 block and reuse cached data
  3. Convolution → Booth Encoding → 4:2 Compressor → Final CPA Sum
  4. Pooling → Downsampling → Dense Matrix Multiplication → Softmax Probabilities
  5. Output → Real-time classification (e.g., Zebra: 98%)

Architecture Benefits

  • Memory Tiling: Reuses local pixel blocks in SRAM to reduce DRAM fetches.
  • Radix-4 Booth Encoding: Cuts partial products by half compared to standard multipliers.
  • 4:2 Compressor Trees: Condenses four inputs into two outputs, shortening critical path.

Project Supervisors

Rashad Ramzan

Rashad Ramzan

Professor
Hassan Saif

Hassan Saif

Professor
Khurram Javed

Khurram Javed

Professor

Engineering Team

Ahmad Shaban

Ahmad Shaban

IC Design Engineer
Awab Younas

Awab Younas

IC Design Engineer
Eeman

Eeman

IC Design Engineer
Fajar Waseem

Fajar Waseem

IC Design Engineer
Humail Nawaz

Humail Nawaz

IC Design Engineer
Kousar Gul

Kousar Gul

IC Design Engineer
Muhammad Mirza

Muhammad Mirza

IC Design Engineer
Osama Mirza

Osama Mirza

IC Design Engineer
Salman Qazi

Salman Qazi

IC Design Engineer
Sana Nazir

Sana Nazir

IC Design Engineer
Ume Kalsoom

Ume Kalsoom

IC Design Engineer

References

  1. S. Dargan, M. Kumar, M. R. Ayyagari, and G. Kumar, "A Survey of Deep Learning and Its Applications: A New Paradigm to Machine Learning," Arch. Comput. Methods Eng., vol. 27, no. 4, pp. 1071–1092, 2020, doi: 10.1007/s11831-019-09344-w.
  2. W. Xie, C. Zhang, Y. Zhang, C. Hu, H. Jiang, and Z. Wang, "An Energy-Efficient FPGA-Based Embedded System for CNN Application," 2018 IEEE Int. Conf. Electron Devices Solid State Circuits, EDSSC 2018, Oct. 2018, doi: 10.1109/EDSSC.2018.8487057.
  3. F. U. D. Farrukh, T. Xie, C. Zhang, and Z. Wang, "Optimization for Efficient Hardware Implementation of CNN on FPGA," Proc. 2018 IEEE Int. Conf. Integr. Circuits, Technol. Appl. ICTA 2018, pp. 88–89, Jul. 2018, doi: 10.1109/CICTA.2018.8706067.
  4. T. Kowsalya, "A novel cognitive Wallace compressor based multi operand adders in CNN architecture for FPGA," J. Ambient Intell. Humaniz. Comput., vol. 12, no. 7, pp. 7263–7271, Aug. 2020, doi: 10.1007/s12652-020-02402-3.
  5. F. U. D. Farrukh et al., "Power Efficient Tiny Yolo CNN using Reduced Hardware Resources based on Booth Multiplier and WALLACE Tree Adders," IEEE Open J. Circuits Syst., pp. 1–1, Jul. 2020, doi: 10.1109/ojcas.2020.3007334.
  6. Y. E. Kim, J. O. Yoon, K. J. Cho, J. G. Chung, S. I. Cho, and S. S. Choi, "Efficient design of modified Booth multipliers for predetermined coefficients," Proc. - IEEE Int. Symp. Circuits Syst., pp. 2717–2720, 2006, doi: 10.1109/ISCAS.2006.1693185.
